#0-80 X 3/8″ Machine Screws, Flat Slot Drive, 82 Degree Countersink, Full Thread, Brass

Description

• Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
• Flat countersunk head screws sit flush with the surface of the material they are inserted into.
• Brass: machinable, ductile, corrosion resistant, excellent electrical and thermal conductivity.

DIMENSIONAL ATTRIBUTES

• Diameter (Nominal): 0
• Thread Pitch: 80
• Diameter (Dimension): 0.060″
• Length (Nominal): 3/8″
• Thread Length (Nominal): 0.340″
• Head Diameter (Minimum): 0.096″
• Head Diameter (Maximum): 0.112″
• Head Height, Overall: 0.035″
• Slot Depth (Minimum): 0.010″
• Slot Depth (Maximum): 0.015″
• Slot Width (Minimum): 0.016″
• Slot Width (Maximum): 0.023″

PRODUCT ATTRIBUTES

• Category: Machine Screws
• System of Measurement: Inch
• Brand: Aspen Fasteners
• Head Style: Flat Countersunk Head
• Head Style Detail: 82 Degree Countersink
• Drive Style: Slotted Drive
• Thread Length: Full Thread
• Thread Direction: Right-Hand Thread
• Material: Brass
• Coating: Uncoated
• Origin: Origin Undefined
