Chicago Valves 3366R6SW002 1/4 in. Stainless Steel Ball Valve – Socketweld, 1000 PSI

Sale!
Chicago Valves 3366R6SW002 1/4 in. Stainless Steel Ball Valve – Socketweld, 1000 PSI

Chicago Valves 3366R6SW002 1/4 in. Stainless Steel Ball Valve – Socketweld, 1000 PSI

Original price was: $8.55.Current price is: $6.22.

44 in stock

SKU: CHV3366R6SW002 Category:

Description

Chicago Valves 3366R6SW002 1/4 in. Stainless Steel Ball Valve – Socketweld, 1000 PSI Description

Series 33 is a 3-piece, 1000 WOG, full port ball valve made from 316 stainless steel with socket weld ends. It features RTFE seats for enhanced chemical resistance and performance in demanding applications.

Features

  • 1000 WOG/CWP
  • ASTM A351 CF8M Stainless Steel
  • Anti-Static Design
  • Blowout Proof Stem
  • Rated for 150 Steam Pressure
  • Vacuum Service to 29″ Hg

Specifications

  • Brand: Chicago Valves
  • Series: 33
  • Type: Ball Valve
  • Connection Type: Socketweld
  • Body Material: 316 Stainless Steel
  • Ball & Stem Material: 316 SST
  • Seat Material: RTFE
  • Body Seal: PTFE
  • Stem Packing: PTFE
  • PSI: 1000
  • OS&Y: Handle

Downloads

Specification Sheet (PDF Download)

Installation Instruction (PDF Download)
