Dixon Dubl-Grip 1 in. NPT Re-Attachable Chrome Plated Brass Curb Pump Hose Coupling

Description

Dixon’s Dubl-Grip is a two-piece re-attachable coupling made of chrome-plated brass that is used with curb pump hoses. The streamlined design prevents damage to the hose and fits smartly on new pump equipment.

Easy Assembly: Hose is held in position by sleeve as body is threaded home, only a wrench is required to assemble the Dubl-Grip®.

Features

• Wide, flat surfaces of body threads protect inside of hose from breaking
• Tapered surfaces of sleeve and body cradle hose, prevent one-point strain from flexing
• Hose is gripped on its full circumference in two places, ensuring a rigid leak-proof connection
• Couplings have standard male NPT threads
• Worn portion of hose can be removed and Dubl-Grip® can be reapplied

Specifications

• Thread Size: 1 in. NPT
• Hose ID: 1 in.
• Hose OD: 1-3/8 in.
• Material: Chrome Plated Brass
• Construction: Octagonal Shape
• Approval: UL Listed

Safety Notes

• Reattach static wire if required.
• Hose service working pressure (including surges and spikes) is never to exceed the maximum recommended working pressure for the fitting. The assembly’s (hose + coupling) maximum working pressure is the lesser of the hose rated working pressure or the coupling rated working pressure.
• WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Downloads

850841 Double Grip Gasoline Hose Coupling Dimensions (PDF Download)
