Donaldson Filter Housing, SG, 225 PSI, 6 in. ANSI

Description

Donaldson SG Series Filter Housings are the top-tier filter housings in the industry. The flanged design incorporated into each of our SG filter housings brings a low pressure drop due to the most efficient flow-path design of the housing. The SG Series standard filter housings include an Econometer differential pressure gauge and external float drain for increased optimization. If you are looking for a more energy-saving approach, the Donaldson SG Series also has an option available that includes the Economizer differential pressure gauge and an UFM-D zero air loss condensate drain. Come to JME for the best variety of filter housings.

Features

• The SG filter housingshave a three part design, allowing for easy installation and seamless maintenance.
• Optimized filter housing constructed for lowest flow velocity, allowing for low pressure drop saves in purification costs of compressed air and gases.
• An addition to the filter housing, the Economizer (with an optional integrated microprocessor) determines the most cost-effective time to exchange the filter elements.
• Another optimal element, the UFM-D zero loss condensate drain increases the energy saving capabilities of the filter housing by allowing zero compressed air to slip out of the cracks.

Specifications

• Connection Type: 6 ANSI Flange
• Maximum Pressure: 232 PSI
• Temperature Range: 14°F to 248°F
• Filter Housing Material: Carbon Steel
• Housing Gasket Material: Aramid Fiber
• Product Dimensions: 15.98 in. x 18.90 in. x 58.46 in.
• Product Weight: 286.6 lbs.
• Shipping Dimensions: 0.57 in. x 1.58 in. x 0.69 in.
• Shipping Weight: 381.47 lbs.

Downloads

Specification Sheet (PDF Download)
