Ingersoll Rand SMB050-15-13V 5 Ton Capacity Manual Chain Hoist With 15ft Lift

Description

Ingersoll Rand SMB050-15-13V 5 Ton Capacity Manual Chain Hoist With 15ft Lift

The Ingersoll Rand SMB050-15-13V 5 Ton Capacity Manual Chain Hoist With 15ft Lift has 1/2 – 5 metric ton Lifting Capacity. A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price. The Ingersoll Rand SMB050-15-13V 5 Ton Capacity Manual Chain Hoist With 15ft Lift is designed by Ingersoll Rand to deliver safe, efficient, and dependable lifting performance across a wide range of applications.

One of the highlights is meets Specifications and HST – 2M standards. Overload protection to deter and reduce downtime and repair costs resulting from abuse. The system supports all steel, low headroom, light weight construction. Engineered for demanding environments, it offers self-adjusting disc type double pawl mechanical load brake. It also provides hardened roller bearings for maximum efficiency and durabilityand 4 layer finish of nickel, copper, nickel, and chrome – rugged enough to last. Ideal for the rental and construction markets.

In practical use, the Ingersoll Rand SMB050-15-13V 5 Ton Capacity Manual Chain Hoist With 15ft Lift excels in applications and is ideal for the rental and construction markets.

Reliability has always been a hallmark of Ingersoll Rand, and the Ingersoll Rand SMB050-15-13V 5 Ton Capacity Manual Chain Hoist With 15ft Lift reflects this tradition by ensuring dependable performance and consistent results over time.

Technical Specifications

Brake Type: Double Pawl, Disc Brake System

Capacity: 11000lbs / 5mt

Chain Fall: 2

Chain Size: 9mm x 27mm

Chain Weight of Lift: 2.4 lbs/ft

Country of Origin: China

ECCN (Export Control Classification Number): EAR99

Finish: Zinc-Nickel-Chrome Plated

Headroom: 28”

Hoist Mount: Hook

Housing Material: Steel

HTS (Harmonized Tariff Code): 8479899499

Lift: 15ft

Product Height: 28” / 711mm

Product Length: 11.2” / 284mm

Product Weight: 46.36kg / 102.2lbs

Product Width: 7.4” / 188mm

Reeving: Double

Shipping Height: 7.2” / 183mm

Shipping Length: 27.2” / 691mm

Shipping Weight: 22.68kg / 50lbs

Shipping Width: 11.2” / 284mm

Standards/Certifications: Ce Certified, Asme B30.16, Hst-2m

TAA Compliant: No

UNSPSC (United Nations Standard Products And Services Code): 24101706

Warranty: 1-year

Chain Type: Alloy Hand

Chain Length: 13ft

Headroom: 711mm

Hook Opening: 2”

Lower Hook: Hardened Swivel Latch Hook

Overload Protection: Yes Pull to

Lift Rated Load: 83lbs

---
