LEWCO SPH Series Heavy Duty Steel Support, 36 in. Width x 8 in. Height

Description

LEWCO’s SPH model heavy duty, stationary “H” style floor supports are easily adjusted and anchored. These supports feature a top pivot plate for applications requiring the conveyor to be set on an angle.

Note: Other widths and heights available. See “Product Drawing” (Downloads tab) for the list of options. Please call 1-800-333-3331 for more information.

Back to Main Listing

Features

• Heavy Duty
• H-Style
• OSHA Safety Blue
• ISO 9001 Quality

Specifications

• Series: SPH Heavy Duty Support
• Part: SPH-8-36
• Width of Support: 36 in.
• Height of Support: 8 in.
• Load Capacity: 3,000 lb. Maximum Load Per Support
• Construction: Formed Steel Inner and Outer Channels, 8 Gauge; Welded Channel Crosstie, 12 Gauge; Base Plate, 8 Gauge
• Top Plate: Standard 8 Gauge Pivot Top Plate is Available Where Adjustable Pitch is Required
• Finish Color: 94 – OSHA/Traffic Blue (RAL 5017)
• Weight: 18.51 lbs.

Note: Other widths and heights available. See “Product Drawing” (Downloads tab) for the list of options. Please call 1-800-333-3331 for more information.

Downloads

Product Manual (PDF Download)

Product Drawing (PDF Download)
