Reotemp BB Series Back Connect Bimetal Thermometer, 5 in. Dia. Dial, Temp Range 0° to 150°F

Description

Reotemp’s bimetal thermometers are reliable and accurate temperature sensors requiring no electricity or wiring. Back connect thermometers are ideal for local, eye-level temperature readings in most process applications. They can be calibrated with a turn of the calibration screw on the back of the dial. For use in process, industrial, refinery , commercial and HVAC industries.

Note: Temperature range is 0° F to 150° F.

Features

• Heavy-duty process grade design
• Accuracy ± 1% Full scale (ASME B40.3 Grade A)
• Hermetically sealed (ASME B40.3)
• Standard external reset for calibration
• Silicone fillable for vibration
• 5 Year limited warranty
• Made in the USA

Specifications

• Series: BB – Back Connect Bimetal Thermometer
• Accuracy: ± 1% Full scale (ASME B40.3 Grade A)
• Dial Size: 5 in. w/ Reset
• Dial Material: White Face with black marks
• Temperature Range: 0° to 150°F
• Increments: 1°F
• Stem Length: 18 – 36 in. – Other lengths available – Call 1 (800) 333-3331 for more information
• Stem Diameter: 1/4 in. (Standard)
• Head, Bezel, Mounting, Bushing, Stems: 300 Series Stainless Steel
• Lens: Glass (Standard)
• Immersion: Minimum 2 in. in liquid, and 4 in. in gas for most ranges
• Mounting Connection: 1/2 in. NPT (Standard)
• Temperature Sensing Area: Last 2 to 4 in. of the stem
• Environmental Protection: IP67, NEMA 6 Rated (Hermetically sealed per ASME B40.3)
• Operating Conditions: Head temperature should not exceed 200°F (150°F if silicone filled) – Stem should not be exposed to continuous temperatures exceeding 50% over range or 800°F (550°F if silicone filled)

Downloads

Back and Bottom Connect Thermometer – Installation Guide (PDF Download)

BB Series 5 in. Dial – 18 in. Stem Drawing (PDF Download)

BB Series 5 in. Dial – 24 in. Stem Drawing (PDF Download)

BB Series 5 in. Dial – 36 in. Stem Drawing (PDF Download)

BB Series Back Connect Bimetal Thermometer Data Sheet (PDF Download)

California Prop 65 Product Compliance (PDF Download)
